Specifications

FEATURES:

• 4 Channel Wireless Handheld Mic System
• Intelligent Frequency Autoscan with IR Synchronization
• Includes 4 Handheld MIC Transmitters with OLED Screen and 4 Mic Clips
• 50 Channels Available per Receiver (200 total)
• 16-Bit Pilot Technology to assist with eliminating frequency interference
• 4 Removable Antennas
• 4 XLR Balanced Outputs + 1 AF Mixed Out (1/4 Jack)
• Batteries Included

WHAT’S INSIDE:

• 4x Hand Held Wireless Microphones (AA batteries included)
• 1x 4-Channel UHF Wireless Receiver
• 4x Detachable UHF Antennas
• 1x Power Supply
• 1x ¼” to ¼” stereo cable
• 4x Microphone clips

PERFORMANCE:

• Wireless Range: 300 ft. (90M) line of site*
• Battery life with full charge: 6-10 hours
• Operating Frequency Range: UHF 540-590MHz
• Dynamic Range: >98dB
• Total Harmonic Distortion: <1%
• Frequency Response: 50HZ ~ 14KHz 3dB
• Signal to Noise Ratio: >85dB
• Audio Output Level: 0-300mV (Balanced: 0-2V)
• Transmitting Power: +10sBM

*Actual wireless range will depend on RF signal absorption

and interference

DIMENSIONS / WEIGHT:

• Receiver Dimensions (LxWxH): 18.9”x5.9”x1.7” / 480x155x45mm (one rack mount unit)
• Receiver Weight: 3.5 lbs. / 1.6kg.
