Specifications

Features:

8 individual channel faders and 1 master fader

24 DMX channels

Compact, portable design

3-Pin and 5-Pin XLR output

Battery Type: PP3 9V (not included)

Control / Connection:

DIP Switches To Set Starting DMX Channel

3pin 5pin DMX Outputs

On/Off Switch

Channel Page button with Indicator LED's

DC9V-12V Power Supply Input

9V Battery slot

Size / Weight:

Length: 4.73” (120mm)

Width: 9.06” (230mm)

Height: 2.23” (56.66mm)

Weight: 1.86 lbs. (0.84kg)

Electrical:

DC9V-12V 300mA min or 9V Battery (Not Included)

Power Consumption: DC9V 40mA 0.36W, DC12V 40mA 0.48W

Approvals / Ratings:

CE Approved

cETLus (Control # 5014475)

IP20

Included Accessories:

• 9V 1A Power Supply with plug adapters

Specifications subject to change without notice.
