Kinta FX ILS
Compact multi-effect with a Kinta, laser, and SMD strobe
Product Features
- Compact multi-effect with a Kinta, laser, and SMD strobe
- ILS compatibility for use in the ILS ecosystem
- D-Fi USB compatibility for wireless Master/Slave or DMX control
- Projects countless razor-sharp multicolor beams
- SMD strobes produce eye-catching strobe effects and chases
- Red and green laser casts hundreds of beams
- Easily control the unit from DMX, Master/Slave, IRC-6, or the digital display
- Save time running cables and extension cords by power linking multiple units
Specifications
DMX Channels
2 or 9
DMX Connectors
3-pin XLR
Light Source (Kinta)
4 LEDs (1 red, 1 green, 1 blue, 1 white) 7.5 W, (2.4 A), 50,000 hours life expectancy
Light Source (Strobe)
16 SMD LEDs (white) 5 W, (1.6 A) 50,000 hours life expectancy
Light Source (Laser)
650 nm/100 mW (red) laser diode, 520 nm/30 mW (green) laser diode
Strobe Rate
0 to 20 Hz
Coverage Angle
118°
Power Linking
17 units @ 120 V; 33 units @ 230 V
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current
25 W, 0.5 A @ 120 V, 60 Hz
Power and Current
24 W, 0.2 A @ 230 V, 50 Hz
Weight
3.8 lb (1.7 kg)
Size
7.4 x 10.3 x 7.4 in (187 x 261 x 187 mm)
Optional Controllers
IRC6
Classified per EN/IEC 60825-1
2014
Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 56, dated May 8, 2019
Approvals
CE, FDA, RoHS, UKCA
