Specifications

Light Source:

• 1 x 10W laser module
• Color temperature: 6,000K - 8,000K
• Beam Angle: 87-degrees
• Lamp life: 10,000 hours
• Diameter of lens: 60mm

Control:

• Display: OLED with 4-button menu system
• DMX Control Modes: 6 or 7 channels
• 5 Built-in lightshows
• Protocols: DMX512 and RDM
• Firmware Upgrade via DMX link
• Smooth dimming from 0~100%
• Adjustable strobe, shutter and pulse effects
• Mirror control: Clockwise/Counter Clockwise; Fast/Slow

Connections:

• DMX Data: 3-pin XLR In/Out
• Power Input: Indoor locking power connector
• Includes laser safety key with on/off lock
• Safety cable connection slot

Electrical:

• Multi-voltage operation: 100-240V, 50-60Hz
• Power Consumption: 20W

Size / Weight:

• Dimensions: 8.7” x 7.7” x 9.4” (221 x 196 x 238mm)
• Weight: 4.4lbs (2 kg)

Approvals:

• IP Rating: IP20
• Laser Accession Number: 2210851-000

Includes:

• Locking Indoor Power Cable
• Hanging Bracket
