COREpar Q60 ILS
COB (Chip-on-Board) LED produces a full spectrum of light with unsurpassed color mixing
Product Features
- COB (Chip-on-Board) LED produces a full spectrum of light with unsurpassed color mixing
- ILS compatibility for use in the ILS ecosystem
- D-Fi USB compatibility for wireless Master/Slave or DMX control
- Included magnetic Fresnel lens allows the flexibility to go from ultra-wide to narrow beam in seconds
- Withstand the harshness of traveling from gig to gig with a robust housing
- Sit-flat housing design hugs the floor and features power and DMX outlets on the side of the unit
- Achieve flicker-free video operation with high-frequency LED dimming
- Save time running cables and extension cords by power linking multiple units
- Point-and-shoot operation of static colors and automated programs with the optional IRC-6 remote
- Create customized colors using the built-in LED display
- Achieve smooth LED fading with built-in dimming curves
- Easily transports in the optional CHS-40 VIP Gear Bag
- Weight: 3.4 lbs. (1.5 kg)
- Size: 7.5 x 7.5 x 8.2 in (192 x 192 x 210 mm)
Specifications
DMX Channels
4 or 9
DMX Connectors
3-pin XLR
Light Source
1 COB LED (quad-color RGBW) 60 W, (2.8 A), 50,000 hours life expectancy.
Strobe Rate
0 to 29 hz
Beam Angle (without lens)
74°
Field Angle (without lens)
100°
Beam Angle (with lens)
20°
Field Angle (with Lenes)
30°
Illuminance (without lens)
320 lux @ 2 m
Illuminance (with lens)
2,796 lux @ 2 m
Color Temperature Range
2700 – 6000K
Cable Length
5ft (1.5 m)
Power Linking
9 units @ 120 V; 17 units @ 230 V
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current
59 W, 0.8 A @ 120 V, 60 Hz
Power and Current
57 W, 0.5 A @ 230 V, 50 Hz
Bracket Mounting Hole
13 mm
Optional Controllers
IRC6, D-Fi USB
Approvals
CE, RoHS, UKCA
