Dynacord

V600:4-US – Multi-channel power amplifier for commercial installations

Overview

Multi-channel power amplifier for commercial installations

Highlights

  • ✓Versatile, lightweight four-channel power amplifier at an attractive price point, recommended for background music and announcements in small to mid-sized commercial installations
  • ✓Unique Dynacord technologies for reduced cost of ownership, with low energy consumption and flexible power-load allocation
  • ✓Easy handling and trouble-free amplifier operation – even under demanding power conditions – in a compact 1RU form factor

Specifications

ELECTRICAL Total rated output power 1 600 W
Number of channels 4
Rated output power 1 4 x 150 W
Output power 4 Ω / 8 Ω / 70 V / 100 V
Maximum output power per channel (power sharing) 500 W / 600 W / 500 W / 600 W
Specifications AMPLIFIER 4 Ω / 8 Ω / 70 V / 100 V
Nominal Gain (+6 dBu input sensitivity, LEVEL 0 dB) 24.0 dB / 27.0 dB / 33.2 dB / 36.2 dB
Signal to Noise Ratio (A‑weighted, ref. to rated output power, LEVEL 0 dB) > -98 dB / > 100 dB / > 101 dB / > 103 dB
THD+N (1/8 RATED OUTPUT POWER, 1 KHZ) < 0.1 %
CONNECTIVITY Type 2 x 6-pin Euroblock, 3.81 mm, male, parallel 1x RJ45 (AES72-1E)
Loudspeaker output 2 x 4-pin Euroblock, 5.08 mm, female
Control port type 1 x 5-pin Euroblock, 3.81 mm, male
GENERAL Signal processing Input Routing, Filter (24 dB/Oct.), Hi-pass 30/50/100/150 Hz, Lo-pass 150 Hz, Peak Limiter
Power requirements 100 V to 240 V, 50 Hz to 60 Hz AC
Power consumption: Idle mode (ecoRAIL with no input signal) < 20 W
Consumption at 1/8 rated output power 115 W
Standby mode (APD active) < 1 W
Protections Audio limiters, high temperature, DC, HF, short circuit, back-EMF, peak current limiters, inrush current limiters, mains over/under voltage protection

Product identifiers

SKU V600:4-US
