Consumer to Pro DI
$68.95
Sale price
$68.95
Regular price
$114.99
The DB100 Laptop DI Box eliminates noise and ground loops that often occur when using consumer audio devices with a PA system. Simply connect its 3.5 mm plug to the headphone jack of a laptop or digital music player, and this compact DI automatically converts the audio signal to a balanced, mic-level XLR output suitable for use with high-powered amplifiers. The volume knob enables additional adjustment of the output level while the ground-lift switch provides control over hum caused by ground loops. Passive and transformer based, this DI does not use a power supply and delivers electrical isolation for convenient, reliable sound preservation.
Specifications
| Application | Convert consumer products to balanced output |
|---|---|
| Cable Length | 10' |
| Color | Black |
| Dimensions | 4.7" (L) x 1.6" (W) x 1.3" (H) |
| Distortion | 0.008% |
| Frequency | 20 Hz-20 kHz |
| Input Attenuation | 20 dB |
| Input Impedance | 100K ohms/1KHZ |
| Input to Output | Stereo to mono |
| Output Impedance | 2.5K-7.5K ohms/1KHZ |
| Product Type | DI Box |
| Signal-to-Noise Ratio | 87 dB |
