Specifications

Contacts: 2+PE

Rated Current: 15A

Rated Voltage: 250V AC VDE (300V AC UL)

Contact Resistance: ≤5mΩ

Dielectric Strength: 4000V DC (1600V/min AC UL)

Insulation Resistance: >1000MΩ

Sevice Life: >1000 Mating Cycles

Shell: PA

Contacts: Cu Alloy

Contact Surface Ag

Ingress Protection: IP65

Flame-retardant Grade" UL94-V0

Temperature Range: -22F to 176F (-30C to +80C)

Standard: IEC61984/UL98
