Specifications

Protocols:

DMX512 (Digital Multiplex)

RDM (Remote Device Management)

Physical:

19" Rack Mount (1-space)

1x Indoor 5-pin XLR Input

1x Indoor 5-pin XLR Thru

8x Indoor 5-pin XLR Outputs

Link Out Termination Switch

DMX / RDM Protocol Switch

Dimensions Weight:

Length: 6" (152.4mm)

Width: 19" (482mm)

Height: 1.73" (44mm)

Weight: 4.87lbs. (2.21kg)

Power:

AC Input: 100-240V 50/60Hz

Power Consumption: 3.1W @ 120V and 3.3W @ 230V

Power Input Protection: Fuse, T1.25A/250 (5.2x20mm)

Thermal:

Ambient Operational Temperature: 32°F to 113°F (0°C to 45°C)

Humidity: <75%

Storage Temperature: 77°F (25°C)

Certifications IP Rating:

cETLus (Control # 5014475)

CE

CB

UKCA

FCC

IP20

Specifications subject to change without notice.
