Name: Electro-Voice LRC-2100-B – High Performance Column Speaker, 1m
Brand: Electro-Voice
SKU: LRC-2100-B
Price: 1529.00 USD
Availability: InStock

Electro-Voice LRC-2100-B – High Performance Column Speaker, 1m

$1,529.00

$1,529.00 $1,914.00

Electro-Voice

LRC-2100-B – High Performance Column Speaker, 1m

Overview

High Performance Column Speaker, 1m

Highlights

✓Twelve 2.5-inch mid-high drivers coupled to proprietary PaSS phase plugs produce a narrow vertical pattern and exceptional LF extension.
✓User can select a narrow or wide vertical pattern (25°/45°), with a 7.5° downward bias to focus energy towards the listener.
✓Weatherized for full exposure, including IP55c
✓rating.
✓SwifTilt Pan-Tilt mounting bracket (patent pending) supports most mounting situations and installs column as close to the mounting surface as possible.
✓Includes rear insert points for suspension.

Specifications

Specifications Frequency range (-10 dB) 1	45 - 16000 Hz
Maximum SPL 2	128 dB narrow 126 dB wide
Axial sensitivity 3	91.5 dB SPL 1W/1m narrow 90 dB SPL 1W/1m wide
Acoustic down-tilt (relative to horizontal)	-7.5°
Specifications Coverage angle HxV 4	180° x 25° (narrow) 180° x 45° (wide)
Power handling (continuous) 5	300 W
Power handling (program) 6	600 W
Peak input voltage	130 V
Nominal impedance	8 Ω
Minimum impedance	6.4 Ω at 280 Hz
Recommended high pass	50 Hz Butterworth 24 dB/oct
Transducer (quantity) size	(2) 6.5 in bass drivers (12) 2.5 in mid-high drivers
Connector type	4-pin Euroblock Input + Pass through (max 10AWG)
Suspension points	(6) M8x20mm
Mounting	SwifTilt Multi-angle Tilt + Pan Bracket
Maximum horizontal pan angle	+- 80° at all down-tilt angles
Vertical down-tilt angles 7	0°, 2.5°, 5°, 7.5°, 10°, 15°, 20°, 25°
IP rating 8	IP55
