Electro-Voice LRC-1060-B

Electro-Voice LRC-1060-B – Column speaker, 0.6m, EN54

$599.00 $753.00
Skip to product information
Electro-Voice LRC-1060-B
  • Electro-Voice LRC-1060-B
  • Electro-Voice LRC-1060-B
Electro-Voice LRC-1060-B – Column speaker, 0.6m, EN54

Electro-Voice LRC-1060-B – Column speaker, 0.6m, EN54

$599.00 $753.00

Electro-Voice

LRC-1060-B – Column speaker, 0.6m, EN54

Overview

Column speaker, 0.6m, EN54

Highlights

  • ✓22.8” (580 mm) high
  • ✓6x 2.5” (63.5 mm) full-range drivers
  • ✓2x 2.5” (63.4 mm) passive radiators
  • ✓20° symmetrical vertical coverage
  • ✓130° horizontal coverage
  • ✓75 Hz-15 kHz

Specifications

Specifications Frequency range (-10 dB) 1 70 Hz – 15,000 Hz
Maximum sound pressure level at a distance of 1 m 2 122 dB
Axial sensitivity 3 90 dB SPL 1W/1m
Coverage angle HxV 4 130° x 20°
Power handling (continuous) 5 100 W
Power handling (program) 6 200 W
Specifications Peak input voltage (Lo-Z) 80 V
Nominal impedance (Lo-Z) 8 Ω
Recommended high-pass ≥70 Hz Butterworth, 24 dB/oct
Transformer taps 70 V line 60 W; 30 W; 15 W; 8 W; 4 W
Transformer taps 100 V line 60 W; 30 W; 15 W; 8 W
Transducer (quantity) size (6) 2.5 in active drivers (2) 2.5 in passive radiators
Connector type 4-pin Euroblock Input + Pass through
Wire size 12AWG (maximum)
Suspension points (2) M8
Mounting SwifTilt Multi-angle Tilt + Pan Bracket
Maximum horizontal pan angle +/- 80° (at all down-tilt angles)
Vertical down-tilt angles 7 0°, 2.5°, 5°, 7.5°, 10°, 15°, 20°, 25°

Product identifiers

SKU LRC-1060-B
