Electro-Voice EVID-P6.2B – Pendant speaker 6.5"

Electro-Voice EVID-P6.2B – Pendant speaker 6.5"

$369.00 $464.00

Electro-Voice

EVID-P6.2B – Pendant speaker 6.5"

Overview

Pendant speaker 6.5"

Highlights

  • ✓Full bandwidth overload protection
  • ✓Front baffle wattage tap adjustment
  • ✓Magnetic grille for easy tap adjustment access
  • ✓Indoor and outdoor use
  • ✓UL1480A and CSA C22.2 certified for indoor installations and protected outdoor installations

Specifications

Rated frequency range 60 Hz - 20 kHz
Sensitivity (SPL 1 W/1 m) 87 dB
Coverage pattern 1 115° conical
Power handling (@ 8Ω) 75 W (with overload protection)
Specifications Rated impedance 8 Ω
Recommended High-Pass frequency 60 Hz
Input configuration 8Ω; 70V/100V
70V/100V power taps 1.8 (70V only)/3.7/7.5/15/30 W
LF transducer 6.5 in (165 mm) high-compliance driver (weatherized cone)
HF transducer 1 in (25 mm) titanium dome
Mounting system Rear mounted suspension points
Acoustic design Ported cabinet, two-way design, internally damped, w/passive crossover
Approvals CE, UL 1480A, CSA 22.2
Cabinet construction UL94V-0 rated enclosure and baffle
Grille construction Powder-coated steel
Colors Black or white
Dimensions (depth x diam.) 11.9 in x 12.2 in (301.0 mm x 310.0 mm)
Net weight 11.65 lb (5.28 kg)
Shipping weight 13.85 lb (6.28 kg)
Included accessories Grille removal tool
Included hardware Pendant Suspension Cable
Material Steel wire rope
Working load limit 10 kg (22 lb)
Length 4.57 m (15 ft.)

Product identifiers

SKU EVID-P6.2B
