Name: Electro-Voice EVID-C8.1S-G2 – Ceiling subwoofer 8" white
Brand: Electro-Voice
SKU: EVID-C8.1S-G2
Price: 349.00 USD
Availability: InStock

Electro-Voice EVID-C8.1S-G2 – Ceiling subwoofer 8" white

$349.00 $440.00

Electro-Voice

EVID-C8.1S-G2 – Ceiling subwoofer 8" white

Overview

Ceiling subwoofer 8" white

Highlights

✓SwiftLock mounting system for quick, safe, and reliable installation.
✓Bezel-less design with easy-attach grille.
✓Front baffle wattage tap adjustment.
✓Includes tile bridge and mounting ring for easy installation.
✓UL 1480A, UL 2043 and CSA 22.2 205 certified.

Specifications

Frequency range (-10 dB) (Hz) 1	45 Hz – 380 Hz
Maximum SPL (continuous) (dB) 2	113 dB
Maximum SPL (peak) (dB) 2	119 dB
Sensitivity (1 W, 1 m) 3	90 dB SPL 1 W, 1 m
Specifications Coverage angle conical (°)	360°
Power handling (continuous) (W) 4	180 W
Power handling (peak) (W) 4	720 W
Long term power handling (continuous) (W) 5	150 W
Long term power handling (peak) (W) 5	600 W
Nominal impedance (Ω) (Low Z)	8 Ω
Transformer taps 70 V line (W)	60 W; 30 W; 15 W; 7.5 W; 3.75 W
Transformer taps 100 V line (W)	60 W; 30 W; 15 W; 7.5 W
LF transducer size (in)	8 in
Material	Steel
Grille material	Powder coated steel
Connector type	4-pin Euroblock Input + Pass through
Wire size (AWG)	12AWG (maximum)
Wire diameter (mm 2 )	3.3 mm 2 (maximum)
