Electro-Voice EVID-C6.2-G2

Electro-Voice EVID-C6.2-G2 – Ceiling speaker 6.5" 70/100V white

$239.00 $300.00
Skip to product information
Electro-Voice EVID-C6.2-G2
  • Electro-Voice EVID-C6.2-G2
  • Electro-Voice EVID-C6.2-G2
Electro-Voice EVID-C6.2-G2 – Ceiling speaker 6.5" 70/100V white

Electro-Voice EVID-C6.2-G2 – Ceiling speaker 6.5" 70/100V white

$239.00 $300.00

Electro-Voice

EVID-C6.2-G2 – Ceiling speaker 6.5" 70/100V white

Overview

Ceiling speaker 6.5" 70/100V white

Highlights

  • ✓SwiftLock mounting system for quick, safe, and reliable installation.
  • ✓Bezel-less design with easy-attach grille.
  • ✓Front baffle wattage tap adjustment.
  • ✓Includes tile bridge and mounting ring for easy installation.
  • ✓UL 1480A, UL 2043 and CSA 22.2 205 certified.

Specifications

Frequency range (-10 dB) (Hz) 1 65 Hz – 20,000 Hz
Maximum SPL (continuous) (dB) 2 109 dB
Maximum SPL (peak) (dB) 2 115 dB
Sensitivity (1 W, 1 m) 3 90 dB SPL 1 W, 1 m
Specifications Coverage angle conical (°) 110°
Power handling (continuous) (W) 4 80 W
Power handling (peak) (W) 4 320 W
Long term power handling (continuous) (W) 5 70 W
Long term power handling (peak) (W) 5 280 W
Nominal impedance (Ω) (Low Z) 8 Ω
Recommended high pass (Hz) 6 60 Hz
Transformer taps 70 V line (W) 30 W; 15 W; 7.5 W; 3.75 W; 1.88 W
Transformer taps 100 V line (W) 30 W; 15 W; 7.5 W; 3.75 W
LF transducer size (in) 6 in
HF transducer size (in) 1 in
Material Steel
Grille material Powder coated steel
Connector type 4-pin Euroblock

Product identifiers

SKU EVID-C6.2-G2
