Name: Electro-Voice ETX-12P-US – 12" powered loudspeaker
Brand: Electro-Voice
SKU: ETX-12P-US
Price: 1599.00 USD
Availability: InStock

Electro-Voice ETX-12P-US – 12" powered loudspeaker

$1,599.00 $2,851.00

Electro-Voice

ETX-12P-US – 12" powered loudspeaker

Overview

12" powered loudspeaker

Highlights

✓12-inch LF SMX woofer
✓1.25-inch HF titanium compression driver
✓2000 W Class-D power amplifier with integrated FIR-Drive DSP
✓135 dB peak SPL

Specifications

Frequency Response (-3 dB)	55 Hz - 20 kHz¹
Frequency Range (-10 dB)	43 Hz - 20 kHz¹
Maximum SPL	135 dB peak²
Specifications Coverage (H x V)	90° x 60°
Power Rating	2000 W
LF Transducer	SMX2120 300 mm (12 in)
HF Transducer	DH3-B 1.25-in titanium compression driver
Crossover Frequency	1600 Hz
Connectors	(2) XLR/TRS combo jack and (1) XLR link output
Enclosure	18mm Plywood with EVCoat
Grille	16AWG steel with powdercoat
Suspension	(8) M10 suspension points
Dimensions (H x W x D)	613 mm x 381 mm x 400 mm (24 in x 15 in x 16 in)
Net Weight	23.6 kg (52.0 lb)
Shipping Weight	26.8 kg (59.1 lb)
Power Consumption	100 - 240 V~, 50 - 60 Hz, 1.6 - 0.8 A³
