Used, Good Working Condition. Dimensions & Weight Height: 3.47" Width: 19.01" (standard 19") Depth: 16.59" Weight (Net): 32.63 lb Performance Frequency Response (-3 dB): 10 Hz – 40 kHz Total Harmonic Distortion (THD): 0.03% Intermodulation Distortion (SMPTE): 0.1% DIM 30: 0.05% Slew Rate: 26 V/μs Signal-to-Noise Ratio (A-weighted): 107 dB...
Used, Good Working Condition.
Dimensions & Weight
Height: 3.47"
Width: 19.01" (standard 19")
Depth: 16.59"
Weight (Net): 32.63 lb
Performance
Frequency Response (-3 dB): 10 Hz – 40 kHz
Total Harmonic Distortion (THD): 0.03%
Intermodulation Distortion (SMPTE): 0.1%
DIM 30: 0.05%
Slew Rate: 26 V/μs
Signal-to-Noise Ratio (A-weighted): 107 dB
Power Output
@ 2Ω (1 kHz, THD 1%): 900 W per channel
@ 4Ω (1 kHz, THD 1%): 600 W per channel
@ 4Ω (20 Hz – 20 kHz, THD < 0.2%): 500 W per channel
@ 8Ω (1 kHz, THD 1%): 380 W per channel
@ 8Ω (20 Hz – 20 kHz, THD < 0.2%): 250 W per channel
Bridged Mono @ 8Ω: 1200 W
Bridged Mono @ 4Ω: 1800 W
Input & Control
Input Sensitivity: +3.1 dBu
Maximum Input Voltage: +21 dBu
Input Impedance (Balanced): 20 kΩ
Amplifier Gain: 32 dB
Network Control (IRIS-Net): No
Design & Construction
Channels: 2
Topology: Class-AB
Cooling: Front-to-rear, 3-stage fans
Impedance Support: 2Ω / 4Ω / 8Ω
Electronics Type: Power Amplifier
