Specifications

Inner conductor: Bare COPPER 19 x 0.12

Inner conductor section: 0.22mm²

Isolation: HDPE Ø 0.95mm

T-568B, Straight Cable Wiring : Blue (Pin 4), Blue-White (Pin 5), Orange (Pin 2), Orange-White (Pin 1), Green (Pin 6), Green-White (Pin 3), Brown (Pin 8), Brown-White (Pin 7)

Number of conductors: 8

Conductor Twisting: Yes

Outer jacket: Flexible PVC

Outer jacket Black

Outer jacket dimensions: Ø 6.5mm

American Wire Gauge: 24 AWG
